Temperature Sensors & Thermocouples

Temperature Sensors & Thermocouples Manufacturer in UAE

National Electric Heaters LLC (NEH) is a UAE-based manufacturer and supplier of Temperature Sensors & Thermocouples, providing reliable and customized temperature measurement solutions for industrial heating, manufacturing, automation, and process control applications.

Our industrial temperature sensors are designed for accurate temperature monitoring, stable performance, and integration with compatible temperature controllers, PLC systems, and industrial equipment.

NEH offers a wide range of thermocouples, RTD temperature sensors, and customized temperature probes based on operating temperature, sensor type, probe dimensions, sheath material, mounting arrangement, and electrical connection requirements.

What Are Temperature Sensors & Thermocouples?

Temperature sensors are devices used to measure temperature and provide signals to monitoring or control systems.

Thermocouples are temperature sensors made from two different metal alloys that generate a small voltage related to the temperature difference between their measuring and reference junctions.

RTD (Resistance Temperature Detector) sensors measure temperature through predictable changes in electrical resistance.

Both technologies are widely used in industrial heating equipment, ovens, furnaces, boilers, HVAC systems, and manufacturing machinery.

Types of Temperature Sensors & Thermocouples

1. Type K Thermocouples

Type K thermocouples are commonly used for industrial temperature measurement in ovens, furnaces, heating equipment, and process machinery.

They provide a broad measurement range and are suitable for many general industrial applications.

2. Type J Thermocouples

Type J thermocouples are used in industrial machinery, heating equipment, plastic processing, and temperature control applications where their operating characteristics are suitable.

3. Type T Thermocouples

Type T thermocouples are commonly used for low-temperature measurement, refrigeration, laboratory applications, and compatible industrial processes.

4. Type R, S & B Thermocouples

Noble-metal thermocouples, including Types R, S, and B, are suitable for selected high-temperature industrial furnaces, laboratory equipment, and specialized thermal processes.

5. PT100 RTD Temperature Sensors

PT100 RTD sensors use a platinum resistance element with a nominal resistance of 100 ohms at 0°C.

They are widely used in industrial temperature monitoring, process control, HVAC systems, and applications requiring good measurement accuracy and stability.

6. PT1000 RTD Temperature Sensors

PT1000 sensors use a platinum resistance element with a nominal resistance of 1000 ohms at 0°C.

They are suitable for industrial temperature monitoring, automation systems, and applications where higher nominal sensor resistance is beneficial.

7. Bayonet Thermocouples

Bayonet thermocouples feature adjustable or fixed bayonet fittings for temperature measurement in plastic processing machinery, injection molding equipment, and heated machine components.

8. Surface Temperature Sensors

Surface-mounted thermocouples and RTD sensors are designed to measure temperatures on pipes, tanks, machinery, heating plates, and other compatible surfaces.

9. Thermocouples with Thermowells

Temperature sensors with thermowells provide mechanical protection and allow sensor removal from compatible pressurized or flowing process systems without directly exposing the sensor to the process medium.

10. Customized Industrial Temperature Probes

NEH offers customized temperature sensor assemblies based on customer drawings, samples, and technical requirements.

Customized Temperature Sensor Specifications

National Electric Heaters LLC provides temperature measurement solutions according to industrial application requirements.

Available customization parameters include:

• Sensor Type: Thermocouple Type K, J, T, R, S, B, PT100, PT1000, and other specified sensor types.
• Temperature Range: Selected according to sensor construction and application conditions.
• Probe Diameter: Customized probe diameters according to installation requirements.
• Probe Length: Customized insertion length and overall dimensions.
• Sheath Material: Stainless steel SS304, SS316, Inconel, and other suitable materials.
• Mounting Connections: BSP, NPT, compression fittings, bayonet fittings, and customized mounting arrangements.
• Electrical Connections: Flexible lead wires, terminal heads, connectors, and terminal blocks.
• Cable Insulation: Fiberglass, PTFE, silicone, ceramic fiber, or other application-compatible materials.
• RTD Wiring Configuration: 2-wire, 3-wire, or 4-wire arrangements.
• Thermocouple Junction: Grounded, ungrounded, or exposed junction configurations.
• Thermowell Design: Customized thermowell length, diameter, material, and process connection.
• Sensor Accuracy: Selected according to the applicable sensor tolerance class and measurement requirements.
• Protective Accessories: Terminal heads, protection tubes, compression fittings, and suitable mounting accessories.

Industrial Applications of Temperature Sensors & Thermocouples

Our temperature measurement solutions are suitable for:

• Industrial ovens and furnaces
• Electric immersion heaters and boilers
• Industrial drying and curing equipment
• Plastic injection molding and extrusion machines
• HVAC and air handling systems
• Chemical and petrochemical industries
• Food and beverage processing
• Pharmaceutical manufacturing
• Industrial automation and process control
• Power generation and utility equipment
• Laboratory and testing equipment
• Heat exchangers and hot water systems

Advantages of Temperature Sensors & Thermocouples

Accurate Temperature Monitoring: Suitable sensor selection supports reliable temperature measurement and process control.

Wide Temperature Coverage: Different thermocouple and RTD technologies accommodate a broad range of industrial operating temperatures.

Customized Construction: Probe dimensions, sheath materials, mounting fittings, and cable configurations can be selected according to application requirements.

Industrial Compatibility: Suitable designs can be integrated into ovens, furnaces, tanks, machinery, and process equipment.

Flexible Installation: Threaded, compression, bayonet, and surface-mounted configurations are available.

Control System Integration: Compatible sensors can connect to temperature controllers, PLCs, data loggers, and monitoring systems.

Why Choose National Electric Heaters LLC (NEH)?

• UAE-based industrial heating and temperature measurement equipment supplier
• Customized thermocouples and RTD temperature sensors
• Type K, J, T, R, S, and B thermocouple options
• PT100 and PT1000 temperature probe solutions
• Flexible probe dimensions, sheath materials, and mounting arrangements
• Customized manufacturing based on drawings or samples
• Technical assistance for temperature sensor selection

Temperature Sensors & Thermocouples Supplier in UAE

National Electric Heaters LLC (NEH) provides customized industrial temperature sensors and thermocouples for manufacturing companies, engineering contractors, HVAC companies, maintenance facilities, and industrial customers throughout the United Arab Emirates.

Whether you require a Type K thermocouple, Type J thermocouple, PT100 RTD sensor, bayonet thermocouple, or customized temperature probe, NEH can assist with a suitable temperature measurement solution based on your technical requirements.

Contact National Electric Heaters LLC (NEH) for technical consultation, customized sensor specifications, and quotations for temperature sensors and thermocouples in the UAE.
